DOWSIL™ TC-2035 CV Thermally Conductive Adhesive Kit Blue 3.2 KG

Product Overview

DOWSIL™ TC-2035 CV Thermally Conductive Adhesive Blue is a 2-part (1:1 mix ratio), 3.3 W/m.K high thermal conductivity silicone adhesive engineered for bonding heat-generating electronic components to heat sinks. Featuring Controlled Volatility (CV) technology, it minimizes low-molecular-weight siloxane volatile species to protect sensitive optics and electrical contacts against fogging and outgassing contamination. Curing cleanly at room temperature or rapidly with heat acceleration via a platinum addition-cure mechanism, it delivers strong, unprimed adhesion to metals, ceramics, and plastics. The 3.2 kg kit (1.6 kg Part A + 1.6 kg Part B) provides an ideal size for medium-scale dispensing, prototype development, and precision assembly lines.

Key Features and Benefits

• High Thermal Conductivity (3.3 W/m.K): Delivers efficient heat dissipation from power devices to heat dissipating structures.
• Controlled Volatility (CV): Low volatile siloxane formulation protects sensitive optics and electrical relays against condensation.
• Primerless Structural Adhesion: Forms a durable, high-strength bond to metals, ceramics, glass, and engineering plastics without primers.
• 1:1 Mix Ratio Convenience: Equal 1:1 mix ratio by weight or volume simplifies automated meter-mix dispensing setup.
• Slump-Resistant Rheology: Holds its shape upon dispensing, resisting sag or movement on vertical surfaces prior to cure.
• Broad Thermal Stability: Maintains physical and thermal integrity across operating temperatures from -45°C to +150°C (-49°F to +302°F).

Technical Specifications

• Appearance / Color: Blue
• Packaging / Net Weight: Kit / 3.2 KG (1.6 KG Part A + 1.6 KG Part B)
• Chemical Base: 2-Part Thermally Conductive Silicone Adhesive (Addition-cure / Platinum catalyst)
• Mix Ratio (by weight / volume): 1:1
• Thermal Conductivity: ~3.3 W/m.K
• Density (Cured): ~3.0 g/cm³
• Service Temperature Range: -45°C to +150°C (-49°F to +302°F)

Applications

• Automotive electronics, ADAS camera/sensor modules, electronic control units (ECUs), and battery management systems (BMS).
• Thermal bonding for sensitive optics, LiDAR, and radar assemblies sensitive to siloxane outgassing.
• Component staking and thermal management in power electronics, inverters, and LED lighting drivers.
• Electronic assemblies requiring structural adhesion combined with high thermal conductivity.

Usage Note: Thoroughly mix Part A and Part B in a 1:1 ratio using meter-mix dispensing equipment fitted with static mixers. Avoid contact with sulfur, amines, or organometallic compounds to prevent platinum catalyst cure inhibition.
